SSTDC is a TRIAC RF dimmer, which allows AC control of dimmable drivers. It is compatible with RF remote controls SSG1Z, SSW1Z, SSRF1Z, SSR1Z (1 zone) SSW4Z and SSR4Z (4 zones) or with a PUSH button. Designed for concealed console installation
| Input voltage AC | 220~240V |
|---|---|
| Dimensions | 52/52/26mm |
| Warranty | 2 years |
| Output voltage AC | 220~240V |
| Frequency | 50~60Hz |
| Maximum power | 220W |
| Max output current | 1A |
| RF frequency | 2.4 GHz |
| Protection rating | IP20 |
| Working temperature range | -10 °C ~ +40 °C |
| Dimming range | 0-100% |
| Control type | RF and PUSH |
| Range | 20m |
